Flexible Indoor LED Screen CH-E Series SMD1515 Curved 7680Hz 600-800cd/m² IP42 Front Maintenance
Подробная информация о продукте:
| Место происхождения: | Китай |
| Фирменное наименование: | CHARMING |
| Сертификация: | CE,ROHS,LVD,EMC,CB,BIS,UL |
| Номер модели: | P2.604 |
Оплата и доставка Условия:
| Количество мин заказа: | 1 |
|---|---|
| Цена: | Подлежит обсуждению |
| Упаковывая детали: | Картонный ящик, деревянный ящик, летный кейс |
| Время доставки: | 30 рабочих дней после оплаты |
| Условия оплаты: | Т/Т,Л/К,Вестерн Юнион,ПайПал,наличные деньги |
| Поставка способности: | 500 шт в неделю |
|
Подробная информация |
|||
| Угол обзора: | 140° | Уровень защиты: | IP42 |
|---|---|---|---|
| Серый уровень: | 14-16 бит | Max.Power: | 100 Вт |
| Плотность пикселей: | 147456 | Режим сканирования: | 1/32Scan |
| Выделить: | Flexible Indoor LED Screen SMD1515,Curved LED Display 7680Hz,Front Maintenance Rental LED Screen |
||
Характер продукции
| Dimension | 500x500x87m |
| Pixel Pitch | 2.604mm |
| Refresh rate | 7680Hz |
| Brightness | 600-800CD/㎡ |
| Maintenance Method | Front maintenance |
| Working temperature | -20~40℃ |
| Cabinet Weight | 7.9 kg |
-
Flexible cabinet supports easily adjustable curvature of ±22.5° for perfect arc and creative stage designs.
-
8 flexible cabinets can form a cylinder with minimum diameter 1.27m for unique shape applications.
-
Hidden latch with graduated lock allows quick curvature adjustment then relock to secure the shape.
-
Retractable locating pin enables full cabinet replacement in large display setups without removing adjacent cabinets.
-
Flexible modules can interlock with regular, curved and right angle cabinets for mixed configuration flexibility.
-
Front maintenance design with die cast aluminum alloy for lightweight and easy handling.
![]()
![]()
![]()
![]()
![]()
